產品名稱: Objective Plan-Apochromat 40x/1.4 Oil DIC M27蔡司物鏡

規格:

產品參數：

規格	Objective "Plan-Apochromat" 40x/1.4 Oil DIC M27	Objective Plan-Apochromat 40x/1.3 Oil DIC M27	Objective Plan-Apochromat 63x/1.4 Oil DIC M27	Objective Plan-Apochromat 100x/1.40 Oil DIC M27
放大倍數	40x	40x	63x	100x
數值孔徑	1.4	1.3	1.4	1.4
工作距離[mm]	0.13	0.21	0.19	0.17
蓋玻片厚度[mm]	0.17	0.17	0.17	0.17
螺紋類型	M27x0.75	M27x0.75	M27x0.75	M27x0.75
浸油	油	油	油	油
視野[mm]	25	25	25	25
齊焦距離[mm]	45.06	45.06	45.06	45.06
